Snare | XP80 (8 inch TCS pad with 3 zone) | |
Tom Pad | TP70 (7 inch rubber pad) | |
Floor Tom Pad | TP70 (7 inch rubber pad) | |
Kick Pad | KP65 (5 inch rubber pad, double foot pedal compatible) | |
Hi-hat Pad | 10 inch pad and HH65 Hi-hat controller | |
Crash cymbal 1 | 10-inch pad with Choke ability | |
Crash cymbal 2 | - | |
Ride cymbal | PCY135 (13 inch pad with 3 zones) | |
Hi-hat Stand | - | |
Footprint (average) | 1,000 mm x 1,100 mm | |
Weight | 25.2 kg |
Dimensions | Width | 303 mm (11-15/16 in) |
---|---|---|
Height | 196 mm (7-11/16 in) | |
Depth | 66 mm(2-5/8 in) | |
Weight | 1.5 kg (3 lb 5 oz) | |
Maximum Polyphony | 256 notes | |
Effects | For each Inst: EQ / Comp / Transient / Insertion (*1), For each Kit: Ambience / Effect 1 / Effect 2 and Master Comp / Master Effect, For overall: Master EQ / Phones EQ (*1) Insertion effects can be used only for specific Inst. | |
Drum kits | Preset: 40 Kits, User: 200 Kits | |
Voices | 712 | |
Click Sets | 30 | |
Tempo | 30 to 300 BPM, Tap Tempo supported. | |
Time signatures | 1/4 to 16/4, 1/8 to 16/8, and 1/16 to 16/16 | |
Subdivisions | Accents, quarter notes, eighth notes, sixteenth notes, and eight-note triplets | |
Others | Individual click volume control, wav import, timer | |
Types | 10 | |
Songs | Preset: 37 songs, User: 1 song | |
Import limit | 1,000 files | |
Maximum loadable sample time | 760 seconds (44.1 kHz, 16 bit, mono), 380 seconds (44.1 kHz, 16 bit, stereo) | |
sample format | WAV | |
Recording time | Internal memory | Maximum of 90 seconds |
USB flash drive | Maximum of 90 minutes per file | |
Format | Record/playback: WAV (44.1 kHz, 16 bit, stereo) | |
Connectors | DC IN | DC IN (+12V) |
Headphones | Headphones (standard stereo phone jack x 1) | |
AUX IN | AUX IN (stereo mini jack x 1) | |
Output | OUTPUT L/MONO, R (standard phone jack, one for each) | |
USB | USB TO DEVICE, USB TO HOST | |
MIDI | MIDI OUT | |
Trigger Input | Trigger inputs 1, 14: (Standard stereo phone, L: Trigger, R: Rim switch / Trigger), 2/3, 4/5, 6/7, 12/13: (Standard stereo phone, L: Trigger, R: Trigger), 8, 9, 10, 11: (Standard stereo phone, L: Trigger, R: Rim switch) *Maximum 14 of pads to be connected (when Y-cable is used) | |
Display | Full Dot LCD (128×64 dot) | |
Accessories | AC adaptor (PA-150 or an equivalent recommended by Yamaha)*2, Owner’s Manual, module holder, module holder wing bolts (x 4), Cubase AI Download Information *2 May not be included depending on your area. Check with your Yamaha dealer. |
